Below the Knee



Lateral BKAAP BKAThe ideal level for amputation in the BKA patient is approximately at the junction of the proximal/middle thirds of the calf to the mid-calf.  The distal third is not acceptable due the the relative avascularity and lack of sufficient soft tissue padding at this level.  The ideal BKA stump in adults is 12.5 to 17.5cm.  Imaging techniques (e.g. ultrasound, angiography, aai, etc) are again useful in helping the clinician decide the exact level of amputation (especially when performed for ischemic disease).  For example, in the patient without significant vasculopathy, the operation will be performed with a pneumatic tourniquet.  Furthermore, both anterior as well as posterior musculocutaneous flaps of equal length will be formed and sutured together creating a surgical scar at the tip of the stump.  This is in contrast to the ischemic patient in which a tourniquet is not applied and in whom the relative increased vascularity of the posterior musculature is used to advantage.  In this case, a long posterior flap is created and wrapped over the distal bone to be sutured just above the site of osteotomy anteriorly (the Burgess technique).

The images shown demonstrates  a BKA of acceptable length.  The patient is wearing a prosthesis.



Lateral BKAAP BKA


These images demonstrate a BKA that is too short to allow for use of a prosthesis.



Post-op BKAPost-op BKA
Immediate post-operative films of a good BKA.  Stump-shrinking cast and skin staples are present.
